ASRock EP2C612D16HM [14/93] English
![ASRock EP2C612D16HM [14/93] English](/views2/1694595/page14/bge.png)
8 9
English
No. Description
1 PSU SMBus (PSU_SMB1)
2 Intelligent Platform Management Bus header (IPMB1)
3 Rear Fan Connector (REAR_FAN2)
4 BMC SMBus Header (BMC_SMB_1)
5 System Panel Header (PANEL1)
6 PCI Express 3.0 x16 Slot (PCIE1)
*For a low prole PCI Express card only
7 Speaker Header (SPEAKER1)
8 PMBus Mode Jumper (PMBUS_SEL_CLK1)
9 PMBus Mode Jumper (PMBUS_SEL_DAT1)
10 PMBus Mode Jumper (PMBUS_SEL_ALT1)
11 NCSI Mode Jumper (NCSI_SEL1)
12 CPU PECI Mode Jumper (PECI_SEL1)
13 CPU Fan Connector (CPU_FAN1)
14 LGA 2011 CPU Socket R3 (Narrow ILM) (CPU_1)
15 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)
16 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2, White)
17 LGA 2011 CPU Socket R3 (Narrow ILM) (CPU_2)
18 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_F1, Blue)
19 2 x 288-pin DDR4 DIMM Slots (DDR4_E2, DDR4_F2, White)
20 Interposer Board Connector (CON21)
21 2 x 288-pin DDR4 DIMM Slots (DDR4_H2, DDR4_G2, White)
22 2 x 288-pin DDR4 DIMM Slots (DDR4_H1, DDR4_G1, Blue)
23 CPU Fan Connector (CPU_FAN2)
24 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, Blue)
25 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, White)
26 USB 3.0 Header (USB3_3_4)
27 SATA3 Connector (SATA_4)
28 Vertical Type A USB 3.0 (USB3_5)
29 Auxiliary Panel Header (AUX_PANEL1)
30 TPM Header (TPM1)
31 Mini SAS HD Connector (MiniSAS_1)
32 SATA3 Connector (SATA_5)
33 SATA SGPIO Connector (SATA_SGPIO1)
