EP2C612D16HM / EP2C612D16HM-2T
2 3
English
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2400
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2400
VRAM DDR3 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
LAN Port 2 + 1 (IPMI) LAN port (RJ45)
LAN Ports with LED (ACT/LINK LED and SPEED LED)
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED)
TPM Header 1
IPMB Header 1
Fan Header 2 x CPU Fans
ATX Power 1 (24-pin) + 2 (8-pin)
USB 3.0 Header 1 (supports 2 USB 3.0 ports)
Type A USB 3.0
Port
1
Mezzanine slot 1 (x8 Mezzanine slot support mezzanine card with 2 x10G
Ethernet (2 x RJ45 by Intel® X540 or 2 x SFP+ by Intel®
82599ES))
Front I/O
connector
1
System BIOS
BIOS Ty pe 128Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- DRAM Voltage Multi-adjustment
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
- MB Temperature Sensing
- Card-side Temperature Sensing
