ASRock EP2C612D16HM [8/93] Specifications
![ASRock EP2C612D16HM [8/93] Specifications](/views2/1694595/page8/bg8.png)
2 3
English
1.2 Specications
EP2C612D16HM / EP2C612D16HM-2T
MB Physical Status
Form Factor Half
Dimension 18.6’’ x 6.5’’ (47.2 cm x 16.51 cm)
Processor System
CPU Intel® Xeon® processor E5-2600 v3/v4* series
*Only E5-2600 V4 CPUs support DDR4 2400.
Socket Dual Socket LGA 2011 R3
*
Please use a narrow type CPU Cooler
Chipset Intel® C612
System Memory
Capacity 16 DIMM slots
Type - Quad Channel memory technology
- Supports DDR4 2400*/2133/1866/1600 RDIMM and
LRDIMM
*Only E5-2600 V4 CPUs support DDR4 2400.
Voltage 1.2V
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
Expansion Slot
PCIe 3.0 x 16 1 slot
M.2 1 slot
Storage
SATA Controller Intel® C612 : 10 x SATA3 (8 from mini SAS HD connector),
support RAID 0, 1, 5, 10
Ethernet
Interface EP2C612D16HM:
1000 /100 /10 Mbps by Intel i350
EP2C612D16HM-2T:
10000 /1000 /100 Mbps by Intel X540 (10G Base-T)
LAN EP2C612D16HM:
2 x RJ45 GLAN by Intel® i350
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
EP2C612D16HM-2T:
2 x RJ45 GLAN by Intel® X540
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
