EP2C612D16HM / EP2C612D16HM-2T
24 25
English
PMBUS Mode Jumper
(3-pin PMBUS_SEL _ALT1)
(see p.6 or p.7, No. 10)
(3-pin PMBUS_SEL_DAT1)
(see p.6 or p.7, No. 9)
(3-pin PMBUS_SEL_CLK1)
(see p.6 or p.7, No. 8)
PMBus loads the data via
BMC chip (Default)
PMBus loads the data via
PCH chip
Chassis ID0 Jumper
(3-pin CHASSIS_ID_0_1)
(see p.6 or p.7, No. 36)
Chassis ID1 Jumper
(3-pin CHASSIS_ID_1_1)
(see p.6 or p.7, No. 35)
Chassis ID2 Jumper
(3-pin CHASSIS_ID_2_1)
(see p.6 or p.7, No. 34)
Single mother board
indication (default)
Reserved for dened system
indication
