1.3 Combination Overview: Outdoor Units of the Sky Air B-Series
Introduction In the tables in this section:
■ “P” stands for pair combination.
■ “T” stands for twin, triple or double twin combination.
FHYBP, FHYP and
FDYP
The table below contains the possible combinations between indoor units (FHYBP, FHYP and FDYP)
and outdoor units of the Sky Air B-series.
FHYCP, FUYP,
FAYP and FHYKP
The table below contains the possible combinations between indoor units (FHYCP, FUYP, FAYP and
FHYKP) and outdoor units of the Sky Air B-series.
FHYBP35B7V1
FHYBP45B7V1
FHYBP60B7V1
FHYBP71B7V1
FHYBP100B7V1
FHYBP125B7V1
FHYP35BV1
FHYP45BV1
FHYP60BV1
FHYP71BV1
FHYP100BV1
FHYP125BV1
FDYP125B7V1
FDYP200B7V1
FDYP250B7V1
Large
c/o
RP71B7V1/W1/T1 T — — P — — T — — P — — — — —
RP100B7V1/W1/T1 TTTTP
— TTTTP— — — —
RP125B7W1/T1 TTTT— PTTTT
— PP— —
RP200B7W1 TTTTTTTTTTTTTP—
RP250B7W1 — TTTTT
— TTTTTT— P
Large
h/p
RYP71B7V1/W1 T — — P — — T — — P — — — — —
RYP100B7V1/W1 TTTTP
— TTTTP— — — —
RYP125B7W1 TTTTTPTTTTTPP
— —
RYP200B7W1 TTTTTTTTTTTTTP
—
RYP250B7W1 — TTTTT
— TTTTTT— P
Outdoor unit
Indoor unit
FHYCP35B7V1
FHYCP45B7V1
FHYCP60B7V1
FHYCP71B7V1
FHYCP100B7V1
FHYCP125B7V1
FUYP71BV17
FUYP100BV17
FUYP125BV17
FAYP71BV1
FAYP100BV1
FHYKP35BV1
FHYKP45BV1
FHYKP60BV1
FHYKP71BV1
Large
c/o
RP71B7V1/W1/T1 T — — P — — P — — P — T — — P
RP100B7V1/W1/T1 TTTTP— TP
— TPTTTT
RP125B7W1/T1 TTTT— PT
— PT— TTTT
RP200B7W1 TTTTTTTTTTTTTTT
RP250B7W1
— TTTTTTTTTTTTTT
Large
h/p
RYP71B7V1/W1 T — — P — — P — — P — T — — P
RYP100B7V1/W1 TTTTP— TP
— TPTTTT
RYP125B7W1 TTTTTPTTPTTTTTT
RYP200B7W1 TTTTTTTTTTTTTTT
RYP250B7W1
— TTTTTTTTTT— TTT
Outdoor unit
Indoor unit
