ESiEN02–01A Specifications
Part 1 – System Outline 1–69
3
1
4
5
3.13 FAYP and FHYKP
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FAYP71BV1 FAYP100BV1 FHYKP35BV1 FHYKP45BV1 FHYKP60BV1 FHYKP71BV1
Heat exchanger Length 1320 mm 778 mm 978 mm
Rows x stages x fin pitch 2 x 12 x 1.4 mm 2 x 11 x 1.75 mm 3 x 11 x 1.75 mm
No. of passes 9 5 9
Face area
0.332 m
2
0.186 m
2
0.226 m
2
Tube type N-hiX tubes N-hiX tubes
Fin type Cross fin coil (multi louvre fins) Cross fin coil (multi louvre fins)
Empty tube hole 2 2 3
Fan Nominal air flow (cooling)
H: 19 m
3
/min
L: 16 m
3
/min
H: 23 m
3
/min
L: 19 m
3
/min
H: 12 m
3
/min
L: 9 m
3
/min
H: 12 m
3
/min
L: 10 m
3
/min
H: 17 m
3
/min
L: 14 m
3
/min
Nominal air flow (heating)
H: 19 m
3
/min
L: 16 m
3
/min
H: 23 m
3
/min
L: 19 m
3
/min
H: 12 m
3
/min
L: 9 m
3
/min
H: 12 m
3
/min
L: 10 m
3
/min
H: 17 m
3
/min
L: 14 m
3
/min
Fan motor model QCL1163MA and QCL1163MB 3D12H1AH1V1 3D12H1J1V1 4D12H1AG1V1
Fan speed 2 steps 2 steps
Fan type Cross frow fan Sirocco fan
Refrigerant circuit Type R407C R407C
Safety and functional devices See page 1–91 and 3–14 See page 1–91 and 3–14
Insulation Heat Foamed polystyrene / foamed polyeth-
ylene
Foamed polystyrene / foamed polyethylene
Weight 26 kg 30 kg 31 kg 33 kg
Decoration panel (option) Model — — BYK45FJW1 BYK71FJW1
Air filter — — Resin net (with mold resistant)
Weight — — 8.5 kg 9.5 kg
Specification FAYP71BV1 FAYP100BV1 FHYKP35BV1 FHYKP45BV1 FHYKP60BV1 FHYKP71BV1
Unit Phase 1~ 1~
Voltage 230 V 230 V
Frequency 50 Hz 50 Hz
Fan motor Phase 1~ 1~
Voltage 230 V 230 V
Power consumption 86 W 101 W Cooling: 92 W
Heating: 59 W
Cooling: 100 W
Heating: 67 W
Cooling: 123 W
Heating: 90 W
FLA (Full Load Amps) 0.3 A 0.4 A 0.2 A 0.3 A 0.5 A
No. of motors x output 1 x 46 W 1 x 49 W 1 x 20 W 1 x 25 W 1 x 45 W
