ESiEN02–01A General Functionality
Part 2 – Functional Description 2–21
3
2
4
5
1
1.15 Fan and Flap Operations
Heating operation The table below contains the fan and flap operations.
Cooling operation The table below contains the fan and flap operations.
Function In... Fan
Flap (FHYCP, FHYKP
and FHYP)
Flap (FAYP)
Remote control
indication
Hot start after defrost Swing operation OFF Horizontal Horizontal Swing
Airflow direction
setting
Set position
Defrost Swing operation Swing
Airflow direction
setting
Set position
Thermostat OFF Swing operation LL Swing
Airflow direction
setting
Set position
Hot start after thermo-
stat OFF (cold air pre-
vention)
Swing operation Swing
Airflow direction
setting
Set position
Stop (error) Swing operation OFF Fully closed
(horizontal)
—
Airflow direction
setting
Fully closed
Overload thermostat
OFF
Swing operation LL Horizontal Swing
Airflow direction
setting
Set position
Function In... Fan
Flap (FHYCP, FHYKP
and FHYP)
Flap (FAYP)
Remote control
indication
Thermostat ON
(microcomputer con-
trolled dry keep mode)
Swing operation L Swing Swing Swing
Airflow direction
setting
Setting Setting Set position
Thermostat OFF
(microcomputer con-
trolled dry keep mode)
Swing operation OFF Horizontal Horizontal Swing
Airflow direction
setting
Setting Setting Set position
Thermostat OFF
(cooling)
Swing operation Setting Horizontal Horizontal Swing
Airflow direction
setting
Setting Setting Set position
Stop (error) Swing operation OFF Horizontal Downward
(horizontal)
—
Airflow direction
setting
Setting Downward
Freeze-up prevention
in microcomputer con-
trolled dry keep mode
(including cooling oper-
ation)
Swing operation L Horizontal Horizontal Swing
Airflow direction
setting
Setting Setting Set position
