2.4 Overview of the Field Settings of the Indoor Units

Field settings The table below contains the possible field settings of all indoor units.

Mode

No.

First

code

No.

Description of the setting

Second code No.

01 02 03 04

10 or 20 0 Filter counter Long Short — —

1 Filter type Long Super long External Oil mist

2 Remote thermistor of the

remote control

TH1 = rem.

control

TH1 = air

return

——

3 Filter display Filter indic. No filter indic. — —

9 Centralized control Yes No — —

11 or 21 0 Number indoor to 1 outdoor Pair Twin Triple Double twin

1 Unified or indiv. set twin Group setting Indiv. setting — —

2 Fan OFF at thermostat OFF LL-speed OFF — —

12 or 22 0 KRP1B51/52/53 X1/X2 output Thermostat

ON

Option Operation Malfunction

3 Fan speed heating thermostat

OFF

LL-speed Set speed — —

5 Automatic restart Disabled Enabled — —

13 or 23 0 Ceiling height setting Normal High Extra high —

1 4-, 3- or 2-way air outlet 4-way 3-way 2-way —

3 Horizontal discharge grill Enabled Disabled — —

4 Air flow direction adjust range

setting

Draft preven-

tion

Standard Ceil soil pre-

vention

—

5 Field fan speed changeover

air outlet

Standard Option 1 Option 2 —

6 External static pressure Normal High Low —

14 or 24 0 Additional timer to guard timer 0 s 5 s 10 s 15 s

15 or 25 1 Humidifier during thermostat

OFF

No Yes — —

3 Drain pump during humidify-

ing (heating)

No Yes — —

5 Ventilation unit indiv. setting No Yes — —

6 Air-cleaner unit indiv. setting No Yes — —
