ESiEN02–01A General Outline: Indoor Units

Part 1 – System Outline 1–27

Part 1

2 General Outline: Indoor Units

2.1 What Is in This Chapter?

Introduction This chapter contains the following information on the indoor units:

■ Outlook and dimensions

■ Installation and service space

■ Components.

General outline This chapter contains the following general outlines:

General outline See page

2.2–FHC35BZ7V1, FHC45BZ7V1, FHC60BZ7V1, FHYC35BZ7V1, FHYC45BZ7V1,

FHYCP35B7V1, FHYCP45B7V1, FHYCP60B7V1 and FHYCP71B7V1

1–28

2.3–FHYBP35B7V1 and FHYBP45B7V1 1–30

2.4–FHYBP60B7V1 and FHYBP71B7V1 1–31

2.5–FHYBP100B7V1 and FHYBP125B7V1 1–32

2.6–FHYCP100B7V1 and FHYCP125B7V1 1–34

2.7–FDYP125B7V1 1–36

2.8–FDYP200B7V1 and FDYP250B7V1 1–37

2.9–FHYP35BV1 and FHYP45BV1 1–38

2.10–FHYP60BV1 and FHYP71BV1 1–40

2.11–FHYP100BV1 1–42

2.12–FHYP125BV1 1–44

2.13–FUYP71BV17 1–46

2.14–FUYP100BV17 and FUYP125BV17 1–48

2.15–FAYP71BV1 and FAYP100BV1 1–50

2.16–FHYKP35BV1 and FHYKP45BV1 1–52

2.17–FHYKP60BV1 and FHYKP71BV1 1–54
