ESiEN02–01A PCB Layout
Part 1 – System Outline 1–159
3
1
4
5
Connectors The table below describes the PCB connectors.
Connector Connected to Description
X1A X2A on A3P
X4A R1T Air thermistor
X5A R2T Heat exchanger thermistor
X6A R3T Discharge thermistor
X7A T1R Transformer
X8A K1M Magnetic contactor (M1C)
X9A S1PH High-pressure switch
X10A S1LP Low-pressure switch
X11A Q1L Thermo switch (M1F)
X12A Q2L Thermo switch (M2F)
X14A M1F Fan motor 1
X15A M2F Fan motor 2
X20A X1M Terminal strip
X21A F1C Over current relay
X22A Y1R 4-way valve
X23A X1A on A2P —
X24A Y1E Expansion valve
X25A J1HC Crankcase heater
X27A Y1S Solenoid valve
