ESiEN02–01A Disassembly and Maintenance: Outdoor Units
Part 5 – Disassembly and Maintenance 5–19
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
1 Front plate 1 34 Filter
2 Front plate 2 35 Filter
3 Assy sealing side plate 36 Fan propeller
4 Top plate assy 37 Washer
5 Bottom plate assy 38 Nut with washer
6 Fixation leg 39 Fan motor
7 Partition plate assy 40 Switch box body
8 Stop valve mounting plate 41 Magnetic contactor + OC
9 Fan motor base 42 Starting relay
10 Air discharge grille 43 PCB assy
11 Suction grille 43.1 Glass tube fuse
12 Handle 44 PCB assy
13 Compressor scroll 45 Transformer
14 Rubber cushion pre-assy 46 Air thermistor
15 Nut with washer 47 Heat exchanger thermistor
16 Bolt for compressor 48 Discharge thermistor
17 Compressor sound absorber 49 Resin PCB support
18 Heat exchanger 50 Running capacitor compressor
19 Receiver 51 Running capacitor compressor
20 4-way valve 52 Start capacitor compressor
21 Coil 4-way valve 53 Capacitor fan motor
22 Motor valve body 54 Resistor assy
23 Coil motor valve 55 Terminal strip
24 Solenoid valve coil 56 Locking card spacer
25 Solenoid valve 57 Compressor cable assy
26 High-pressure switch 58 Thermistor fixing plate
27 Low-pressure switch 59 Thermistor mounting spring
28 Charge valve 60 Thermistor mounting spring
28.1 Valve core (service port) 61 Filter
28.2 Blind cap (service port) 62 DAIKIN name plate
29 Stop valve assy 63 Stop valve cover
30 Stop valve assy 64 Bottom tray assy
31 Service cap 65 Packing case shell
32 Flare nut 66 Packing cushion assy
33 Flare nut —
