ESiEN02–01A Disassembly and Maintenance: Outdoor Units
Part 5 – Disassembly and Maintenance 5–27
3
5
1
5
Components The table below contains the components of the exploded view.
No. Component No. Component
A1 Compressor E18 Discharge thermistor
A2 Rubber cushion pre-assy E19 Fan motor
A3 Hexagon bolt E20 Fan motor
A4 Round plain washer for wood E22 Thermistor clamp
A5 Insulation cover E23 Coil motorized valve
A6 Head cover E24 4-way valve coil assy
A7 Insulation cover F3 Side plate right
A8 Crankcase heater F4 Side plate left
B1 Heat exchanger assy F5 Front plate upper
B1.1 Distributor assy F6 Front plate lower
B2 Liquid receiver assy F7 Front plate lower
B3 4-way valve assy F8 Fan motor base
B3.1 Filter F9 Upper stay
B3.2 Muffler F10 Bypass prevention plate
B3.3 4-way valve body F11 Support rear
B3.4 High-pressure switch F12 Support front
B3.5 Low-pressure switch F13 Top plate air outlet
B3.6 Check valve F14 Discharge grille
B3.6.1 Fitting body F15 Suction grille
B3.6.2 Valve core F16 Stop valve mounting plate assy
B3.6.3 Service port F17 Cover
B3.7 Stop valve assy F18 Bottom plate (sheet metal)
B3.8 Packing for flange F19 Foundation leg
B3.9 Hexagon bolt F20 Thermistor mounting spring
B4 Motor operated valve assy F21 Thermistor mounting spring
B4.1 Motor operated valve body F23 Trough hole cover
B4.2 Solenoid valve K1 DAIKIN name plate
B4.3 Solenoid valve coil assy K3 Supplied pipe (gas side)
B4.4 Filter K3.1 Mating flange
B4.5 Check valve K3.2 Packing for flange
B4.6 Check valve K4 Supplied pipe (gas side)
B4.7 Stop valve assy L1.1 Wire harness
C1 Fan blade assy L1.2
C1.1 Set screw L1.3
E1 Switch box assy L1.4
E2 Switch box main body L1.5
E3 Switch box cover assy L1.6
E4 PCB assy L1.7
E4.1 Glass tube fuse L1.8
E5 Magnetic contactor / Electromagnetic
switch
L1.9
E6 Terminal and cover L1.10
E7 PCB assy L1.11
E8 Locking guard spacer L1.12
E9 Resin PCB support L1.13
E11 Capacitor L1.14
E12 PCB assy L1.15
E13 Power supply transformer L1.16
E15 Power supply fixing case L1.17
E16 Air thermistor L1.18
E17 Heat exchanger thermistor —
