Teka VR 90 4G AI TR AL [19/30] Models
![Teka VR 90 4G AI TR AL [19/30] Models](/views2/1069795/page19/bg13.png)
GB
19
Models
CG Lux-70 CG Lux-70 CG Lux-70 CG Lux-75 CG Lux-86
4G AI 5G AI 5G AI TR 2G AI TR 3G AI TR
CG Lux-70 CG Lux-70 CG Lux-70 CG Lux-70 CG Lux-70 CG Lux-75 CG Lux-86
4G AIAL 5G 5G AI AL 5G AI TR AL 5G TR 2G AI TR AL 3G AI TR
AL
Dimensions in mm
Length
710 710 710 710 710 750 860
Width
510 510 510 510 510 450 450
Height
115 115 115 115 115 115 115
Glass thickness
8 8 8 8 8 8 8
Dimensions of the space in the unit mm
Length
690 690 690 690 690 670 815
Width
492 492 492 492 492 350 405
Depth 70 70 70 70 70 70 70
Power per burner and hotplate
Triple crown gas
burner 3.5 kW.
1 1 2 2
Rapid gas
burner 3 kW.
1 2 2 1 1
Semi-rapid gas
burner 1.75 kW.
2 2 2 2 2 1
Auxiliary gas
burner 1 kW.
1 1 1 1 1
Rapid electric hotplate
ø 145 mm, 1000 W.
Rapid electric hotplate
ø 145 mm, 1,500 W.
Electric hotplate
ø 180 mm, 1500 W.
Electrics
Nominal power
(W) for 230 V* 0,6 0,6 0,6 0,6 0,6
Supply
voltage V.
SEE THE APPLIANCE’S RATING PLATE
Frequency Hz.
50-60 50-60 50-60 50-60 50-60
Gas
Maximum
power kW.
7,5 10,5 10,5 11 11 7 8,75
* For voltages other than 230 V please consult the appliance’s rating plate
