Teka VR 90 4G AI TR AL [23/30] Turning on the electric hotplates
![Teka VR 90 4G AI TR AL [23/30] Turning on the electric hotplates](/views2/1069795/page23/bg17.png)
GB
23
for more than 15 seconds. If after 15
seconds the burner has not lit, stop the
device and open the compartment door
and/or wait at least 1 minute before
attemting a futher ignition of the burner.
In the event of the burner flames
being accidentally extinguished, turn
off the burner control and do not
attempt to re-ignite the burner for at
least one minute.
Turning on the electric
hotplates
The electric hotplates are controlled by a
switch with seven positions. To get different
levels of power, all you need to do is to turn
the appropriate knob and set it to the posi-
tion you want. (See fig. 21).
The pan should be placed on the hotplate
before ignition.
The power corresponding to each of the
switch’s positions is as follows:
When this type of hotplate is in
operation or has recently been in ope-
ration, some areas will be hot and can
burn.
The hotplate with the red dot (1500 W.)
heats up rapidly and achieves its maxi-
mum during around the first five minutes,
after which its power decreases to 500 W.,
at which point the temperature becomes
constant.
On the control panel, there is a square with
circles inside that show which hotplate
corresponds to which control.
There is also an indicator light on the panel
that shows whether one or more hotplates
are in operation.
After being connected, or if the hotplate
has not been used for some time, the
moisture absorbed by the insulation needs
to be eliminated - to dry it out, turn the hot-
plate on with no pan on it for five minutes
at switch position 2.
TEKA Industrial S.A. reserves the right to
alter its appliances in any way it deems
necessary or useful while not altering its
basic characteristics.
‘Hotplate in operation’ indicator
Control indicator
Indicator light
fig. 21
Hotplate Ø 145 - 1500 W.
Power
0
1
2
3
4
5
6
Switched off
135 W.
165 W.
250 W.
500 W.
750 W.
1500 W.
Control set to
