* Turn on the gas at the mains or turn the
gas cylinder’s tap.
* Press the control knob and at the same
time turn it anti-clockwise to the On posi-
tion (the spark symbol). When the gas
ignites, keep the knob at this position for
between 5 and 10 seconds to enable the
safety thermocouple to work.
* Set the control to the position required.
The ignition (ceramic and electrode)
should be cleaned regularly and care-
fully in order to avoid ignition problems.
Check, too, that the grooves in the bur-
ners have not become obstructed.
Use flat-bottomed pans and check that
they sit squarely on the grid, so that when
food boils the pan does not slip (do not use
pans with a concave or convex base).
With hobs CG Lux-75 and CG Lux-86 you
can use pans with a concave base (e.g.
woks) on the grid that is designed for this
use.
Only pans with a minimum diameter of 140
mm should be used on each burner. If you
wish to use a pan with a diameter of 120
mm or smaller, it should be placed on the
auxiliary burner. On hobs CG Lux-75 and
CG Lux-86, the grid accessory has to be
used (element A in fig. 27).
Please note:
When the burners are in opera-
tion or have recently been in operation,
the hob will be hot in places and this
can lead to burns. Children should be
kept well away.
For safety reasons, we advise that
the instructions provided by the gas
supply company are followed and that
the supply tap is turned off when the
hob is not in use.
If a gas smell is noted, the gas
intake to the hob should be shut off and
the room ventilated. The gas installa-
tion and the hob should also be chec-
ked by a specialised technician.
The device shall not be operated
GB
22
‘Burner in operation’ indicator
Control indicator
Off position
Maximum gas position
Minimum gas position
Burner on position
fig. 20
‘Burner in operation’ indicator
Knob position when not in use
Maximum gas position
Minimum gas position
fig. 19
