Teka VR 90 4G AI TR AL [20/30] Table 2
![Teka VR 90 4G AI TR AL [20/30] Table 2](/views2/1069795/page20/bg14.png)
GB
20
Technical data
COMMON FEATURES FOR ALL MODELS
WITH ELECTRIC HOTPLATES AND AUTO-
MATIC IGNITION
The supply voltage and frequency will be
as shown on the rating plate.
If an electric hotplate gets cracked, the
hob should be disconnected from the elec-
tricity current.
COMMON FEATURES FOR ALL
MODELS WITH GAS BURNERS
Warnings:
a) Before installation, make sure that the
local supply conditions (the gas type and
pressure) are compatible with the applian-
ce’s setup.
b) The setup conditions for this appliance
are written on the label (or the rating
plate).
c) This appliance should not be connected
to a device for removing combustion
products. It should be installed and con-
nected in compliance with the current ins-
tallation standards. Special attention
should be paid to the regulations applying
to ventilation.
A gas cooking appliance produ-
ces heat and moisture at the site where
it is installed. The kitchen should be
provided with suitable ventilation: natu-
ral ventilation sources should be kept
clear, a window opened, or an effective
mechanical ventilation system device,
such as a hood, installed.
The intense and prolonged use
of the appliance may call for comple-
mentary ventilation, such as opening a
window, or more efficient ventilation
such as increasing the power of the
mechanical ventilation if this exists.
Class 3 Hob.
You should keep the Guaran-
tee Certificate or, where relevant, the
technical datasheet, together with
the Instruction Manual for the dura-
tion of the useful life of the appliance.
It has important technical information
about the appliance.
Country
France
United Kingdom
Greece
Italy
Category
II2E+3+
II2H3+
I3+
II2H3+
Table 2
CG Lux-60, CG Lux-70,
CGC 4G, CG.1 4G, CG.1 3G 1P
Table 3
Semi-rapid
1,75
0,17
0,19
0,13
0,13
0,47
Burner
Nominal Calorific Consumption
Nominal Consumption*
Auxiliar
1
0,10
0,11
0,07
0,07
0,33
Rapid
3
0,29
0,33
0,22
0,21
0,77
Triple
crown
3,5
0,33
0,38
0,25
0,24
--
s
kW
G-20 (Nm
3
/h)
G-25 (Nm
3
/h)
G-30 (Kg/h)
G-31 (Kg/h)
mbar
20
25
29
37
* Consumption over Gross Calorific Value (H )
Performance %
CCR CG Lux-75 and CG Lux-86
VR 90 4G, CG Lux-70 5G TR
kW
kW
kW
1,55
1,55
>52
0,77
--
>52
0,33
--
--
0,47
0,47
>52
