SiE39-404 Special Control
Function 89
3.4 Pump-down Residual Operation
3.4.1 Pump-down Residual Operation in Cooling Operation
* Actuators are based on RXYQ16M.
3.4.2 Pump-down Residual Operation in Heating Operation
* Actuators are based on RXYQ16M.
Actuator Master unit operation Slave unit operation
Compressor 210 Hz + OFF + OFF OFF
Outdoor unit fan Fan control OFF
Four way valve OFF OFF
Main motorized valve (EV1) 1400 pls 0 pls
Subcooling motorized valve (EV2) 0 pls 0 pls
Hot gas bypass valve (SVP) ON OFF
Oil equalization valve (SVO) ON OFF
Receiver gas discharging valve (SVG) ON ON
Non-operating unit liquid pipe stop
valve (SVSL)
ON ON
Ending conditions
• 5 min.
• Pe<0.5 MPa
• Td>110°C
or
Actuator Master unit operation Slave unit operation
Compressor 124 Hz + OFF + OFF OFF
Outdoor unit fan STEP8 STEP5
Four way valve ON ON
Main motorized valve (EV1) 0 pls 0 pls
Subcooling motorized valve (EV2) 0 pls 0 pls
Hot gas bypass valve (SVP) ON OFF
Oil equalization valve (SVO) ON OFF
Receiver gas discharging valve (SVG) ON ON
Non-operating unit liquid pipe stop
valve (SVSL)
ON ON
Ending conditions
• 30 sec.
• Pe<0.25 MPa
• Td>110°C
or
