SiE39-404 Option List
Appendix 303
4.2 Option Lists (Outdoor Unit)
RXYQ5 ~ 16MY1B
3D039551A
RXYQ18 ~ 32MY1B
3D039552A
RXYQ34 ~ 48MY1B
3D039553A
Optional accessories RXYQ5MY1B
RXYQ8MY1B
RXYQ10MY1B
RXYQ12MY1B
RXYQ14MY1B
RXYQ16MY1B
Cool/Heat Selector KRC19-26A
Cool/Heat
Selector
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRP26M22H,
KHRP26M33H
(Max. 4 branch)
(Max. 8 branch)
KHRP26M22H,
KHRP26M33H,
(Max. 4 branch)
(Max. 8 branch)
KHRP26M22H,
KHRP26M33H,
KHRP26M72H
(Max. 4 branch)
(Max. 8 branch)
(Max. 8 branch)
Refnet joint
KHRP26M22T KHRP26M22T,
KHRP26M33T,
KHRP26M22T,
KHRP26M33T,
KHRP26M72T
Kit of air discharge duct KPF26B160 KPF26B280 KPF26B450
Central drain pan kit KWC26B160 KWC26B280 KWC26B450
Refrigerant leak detector kit KFLD26A
Optional accessories
RXYQ18MY1B
RXYQ20MY1B
RXYQ22MY1B
RXYQ24MY1B
RXYQ26MY1B
RXYQ28MY1B
RXYQ30MY1B
RXYQ32MY1B
Cool/Heat Selector KRC19-26A
Cool/Heat
Selector
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRP26M22H, KHRP26M33H, KHRP26M72H, KHRP26M73H
(Max. 4 branch) (Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint KHRP26M22T, KHRP26M33T, KHRP26M72T, KHRP26M73T
Outdoor unit multi connection piping kit BHFP22M90
Pipe size reducer KHRP26M73TP, KHRP26M73HP, BHFP22M90P
Kit of air discharge duct
KPF26B280 × 2
KPF26B280
KPF26B450
KPF26B450 × 2 KPF26B450 × 2
Central drain pan kit
KWC26B280 × 2
KWC26B280
KWC26B450
KWC26B450 × 2 KWC26B450 × 2
Refrigerant leak detector kit KFLD26A
Optional accessories
RXYQ34MY1B
RXYQ36MY1B
RXYQ38MY1B
RXYQ40MY1B
RXYQ42MY1B
RXYQ44MY1B
RXYQ46MY1B
RXYQ48MY1B
Cool/Heat Selector KRC19-26A
Cool/Heat
Selector
Fixing box KJB111A
Distributive
Piping
Refnet header
KHRP26M22H, KHRP26M33H, KHRP26M72H, KHRP26M73H
(Max. 4 branch) (Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint KHRP26M22T, KHRP26M33T, KHRP26M72T, KHRP26M73T
Outdoor unit multi connection piping kit BHFP22M135
Pipe size reducer KHRP26M73TP, KHRP26M73HP, BHFP22M90P
Kit of air discharge duct
KPF26B280 × 2
KPF26B450
KPF26B280
KPF26B450 × 2
KPF26B280
KPF26B450 × 2
KPF26B450 × 3
Central drain pan kit
KWC26B280 × 2
KWC26B450
KWC26B280
KWC26B450 × 2
KWC26B280
KWC26B450 × 2
KWC26B450 × 3
Refrigerant leak detector kit KFLD26A
