SiE30-408 Collection and Playback of Data on Checker
Service Checker Type3 Application Edition 153
A number of “ON” and “OFF” are mixed on the current setting, thus making the
window hard-to-read. Therefore, make settings in accordance with the procedure
shown below, in order to facilitate reading.
The following window will be displayed.
Highlight columns displaying ON or OFF.
With the columns highlighted, click on the
“Edit” tab and then highlight the “Replace”.
Enter characters“OFF” to be replaced.
Leave here blank (arbitrary).
Check off thisbox.
Click on the “Replace All”button.
