Method of Troubleshooting SiE30-408
86 Troubleshooting
Operation in Heating
From discharge of compressor
Internal piston movesaccording to
pressure difference between high
pressure and low pressure.
Coil: energize
Internal plunger moves
To indoor
heat exchanger
To suction of
compressor
From outdoor unit
heat exchanger
