Method of Troubleshooting SiE30-408
78 Troubleshooting
2. Construction of Thermistor
For Thermistor
Malfunction
Soldering (with eutectic solder)
No. Name Material
1 Thermistor Metallic oxide Glass Dumet wire
2 Coat agent 1 Silicon resin
3 Coat agent 2 Epoxy resin
4 Filling agent Epoxy resin
5 Protective pipe Phosphor deoxidized copper
Moisuture enters into the thermistor through the
clearance between lead wire and filler.
Electrolytic corrosion (transfer of cuprous oxide) generated.
