 NOTE:

1.The Switch is a power-required device, it means, the Switch

will not work until it is powered. If your networked PCs will

need to transmit data all the time, please consider use an

UPS (Uninterrupted Power Supply) for your Switch either

through POE port or DC 12V. It will prevent you from net-

work data loss.

2. In some area, installing a surge suppression device may

also help to protect your Switch from being damaged by

unregulated surge or current to the Switch or the power

adapter if DC12V power is in use.

3. Consult the network administrator for the information of

802.3af Power over Ethernet. Port#1 only accept 802.3af

power supply, connect with any other non-standard 802.3af

equipments to it may cause the Switch malfunction.

LED Indicators:

PWR This indicator lights green when the Switch is receiving power (ei-

ther from 12VDC or from POE), otherwise, it is off.

LNK/ACT This indicator light green when the port is connected to an Ethernet

or Fast Ethernet station, if the indicator is blinking green, it will be

transmitting or receiving data on the network.

100 This LED indicator light orange when a Fast Ethernet station is con-

nected. It remains OFF, if an Ethernet station is connected.

POE This LED indicator light green when port#1 POE in-line power is

detected. Remains off means NO 802.3af in-line power is detected.

Blink shows sending signal to 802.3af in-line power device for

power feeding.
