Planet FSD-803PE [22/24] Auto negotiation
![Planet FSD-803PE [22/24] Auto negotiation](/views2/1070970/page22/bg16.png)
20
The Switch performs “Store-and-forward” therefore, no error packets occur. More reliably,
it reduces the re-transmission rate. No packet loss will occur.
Auto-Negotiation
The STP ports on the Switch have built-in “Auto-Negotiation.” This technology
automatically sets the best possible bandwidth when a connection is established with
another network device (usually at Power On or Reset).
This is done by detect the modes and speeds at the second of both device is connected
and capable of. Both 10Base-T and 100Base-TX devices can connect with the 100Base-TX
port in either Half- or Full-Duplex mode.
If attached device is: 100Base-TX port will set to:
10Mbps, no auto-negotiation 10Mbps
10Mbps, with auto-negotiation 10/20Mbps (10Base-T/Full-Duplex)
100Mbps, no auto-negotiation 100Mbps
100Mbps, with auto-negotiation 100/200Mbps (100Base-TX/Full-Duplex)
