Planet FSD-803PE [7/24] Other key features are

place where AC adapter is not required. Through the UTP wire, the power of

the Switch can be managed from the central/backbone and also without fear of

power shutdown.

• The Switch combine dynamic memory allocation with store-and- forward

switching to ensure that the buffer is effectively allocated for each port, while

controlling the data flow between the transmit and receive nodes to guarantee

against all possible packet loss.

• The Switch is an unmanaged 10/100 Fast Ethernet Switch that offers solutions

in accelerating small Ethernet workgroup bandwidth.

Other key Features are:

• Auto MDI/MDI-X on each port for Uplink to another switch, hub or repeater.

• Store and forward switching scheme capability. As the result of complete frame

checking and error frame filtering, this scheme prevents error packages from

transmitting among segments.

• NWay Auto-negotiation for any port. This allows for auto-sensing of speed (10/

100Mbps) thereby providing you with automatic and flexible solutions in your

network connections.

• Flow control for any port. This minimizes dropped packets by sending out col-

lision signals while the port’s receiving buffer is full. Note that flow control is

only available in half-duplex mode.

• Data forwarding rate per port is at wire-speed for 100Mbps speed.

• Data forwarding rate per port is at wire-speed for 10Mbps speed.

• Data filtering rate eliminates all error packets, runts, etc., per port at wire-

speed for 100Mbps speed.

• Data filtering rate eliminates all error packets, runts, etc., per port at wire-

speed for 10Mbps speed.

• 2K active MAC address entry table per port with self-learning and table-aging

for the Switch.
