Chapter 5

TECHNICAL SPECIFICATIONS

Model FSD-803PE

Standards IEEE802.3 10Base-T Ethernet

IEEE802.3u 100Base-TX Fast Ethernet

IEEE802.3af Power over Ethernet

Protocol CSMA/CD

Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full duplex);

Fast Ethernet: 100Mbps (half duplex), 200Mbps (full

duplex)

Topology Star

Network Cables EIA/TIA- 568 100-ohm STP (max. 100 m);

10BaseT: 2-pair UTP Cat. 3,4,5;

100Base-TX: 2-pair UTP Cat. 5;

POE: 4-pair UTP Cat. 5

Number of Ports 8 x 10/100Mbps ports

DC inputs DC jack: DC 12V/1A max.

POE (port#1): DC48V / 150mA max.

Power Consumption 4.3watt max. / 14.5BTU per hour

POE Port 1; Port # 1

Pin contact of POE

port

Contact 4, 5, 7, 8; power injection auto-detect by

IEEE802.3af

Temperature Operating: 0 ~ 50 degree C,

Storage: -10 ~ 70degree C

Humidity Operating: 10% ~ 90%,

Storage: 5% ~ 90%

Dimensions

(W x D x H, mm)

160 x 80 x 28

EMI FCC Class B, CE

MAC Address Learn-

ing:

Automatic update
