Performance
Transmit Method: Store-and-forward
RAM Buffer: 4M
Filtering Address Table: 2K entries per device
Packet Filtering/
Forwarding Rate:
10Mbps Ethernet: 14,880/pps
100Mbps Fast Ethernet: 148,800/pps
MAC Address Learning: Automatic update
10-000039-000.indd 2004/8/27, �� 05:3716
