Chapter 2

UNPACKING AND SETUP

This chapter provides unpacking and setup information for the Switch.

Unpacking

Open the shipping cartons of the Switch and carefully unpacks its contents. The carton

should contain the following items:

• One 8-port 10/100Mbps Ethernet Switch

• One External power adapter (optional, vary on model)

• This User’s manual

If any item is found missing or damaged, please contact your local reseller for

replacement.

Setup

The setup of the Switch can be performed using the following steps:

• The surface must support at least 1.5 kg for the Switch.

• [Option] Confirm with the network administrator for the information of the POE

device if the Switch is plan to connect with a 802.3af in-line power hub or

switch

• [Option] The power outlet should be within 1.82 meters (6 feet) of the

Switch.

• [Option] Visually inspect the DC power jack and make sure that it is fully se-

cured to the power adapter.

• Make sure that there is proper heat dissipation from and adequate ventilation

around the Switch.

• Do not place heavy objects on the Switch.

 NOTE:

To prevent from device damage, please use the bundled AC

Adapter before power on your Switch. And never use any

other non-802.3af POE device to port #1 of the Switch.
