Please also check the PCs in the network, for some times, if one of the PCs send-
ing abnormal broadcast to the network it will also affect the overall network per-
formance. You can check the LED of the switch to diagnose the symptom. Remove
all the connection and plug-in one by one, if the LNK/ACT LED is blinking all the
time (never stop), please isolate this PC and see if the performance will goes back
to normal if the reset PCs are connected back to the switch.
