TPower X58/TPower X58A
9
B. Memory Capacity
DIMM Socket
Location
DDR3 Module
Total Memory Size
DDR3_A1 256MB/512MB/1GB/2GB / 4GB
DDR3_A2 256MB/512MB/1GB/2GB / 4GB
DDR3_B1 256MB/512MB/1GB/2GB / 4GB
DDR3_B2 256MB/512MB/1GB/2GB / 4GB
DDR3_C1 256MB/512MB/1GB/2GB / 4GB
DDR3_C2 256MB/512MB/1GB/2GB / 4GB
Max is 24GB.
C. Triple Channel Memory installation
Triple Channel function will be activated as the following table shows:
(O means memory installed; X, not installed.)
Triple Channel
Status
DDR3
A1
DDR3
A2
DDR3
B1
DDR3
B2
DDR3
C1
DDR3
C2
Enabled X O X O X O
Enabled O O O O O O
The DRAM bus width of the memory module must be the same (x8 or x16)
Attention: Memory module must be installed in one of DDR3 channel _2 slots
(DDR3_A2, DDR3_B2, DDR3_C2) to boot the system.
