B. Memory Integration Test (M.I.T.)
This function is under “Overclocking Navigator Engine” item.
MIT allows users to test memory compatibilities, and no extra devices or
software are needed.
Step 1
The default setting under this item is “Disabled”; the condition parameter should
be changed to “Enable” to proceed this test.
BIOS SETUP UTILIT
Y
Main Advanced
PCIPnP Boot
Chipset O.N.E
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
=========== Automate OverClock System ===========
============ Manual OverClock System ============
Auto OverClock System [V6-Tech Engine]
DRAM Timing Configuration
Clock Gen Configuration
Current QPI Frequency :
Current Memory Frequency :
Current Uncore Frequency :
Intel(R) SpeedStep(tm) tech [Enabled]
Ratio CMOS Setting [24]
CPU Frequency Setting [133]
QPI Links Speed [Full-Speed]
QPI Frequency [4.800GT]
Uncore Frequency [Auto]
DRAM Frequency [Auto]
Command Rate [Auto]
> Intel PPM/Turbo Mode Configuraiton
>
>
> Voltage Control
Memory Test [Disabled]
Exit
Op ti ons
Disabled
Enabled
↓
BIOS SETUP UTILIT
Y
Main Advanced
PCIPnP Boot
Chipset O.N.E
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
=========== Automate OverClock System ===========
============ Manual OverClock System ============
Auto OverClock System [V6-Tech Engine]
Current QPI Frequency :
Current Memory Frequency :
Current Uncore Frequency :
Intel(R) SpeedStep(tm) tech [Enabled]
Ratio CMOS Setting [24]
CPU Frequency Setting [133]
QPI Links Speed [Full-Speed]
QPI Frequency [4.800GT]
Uncore Frequency [Auto]
DRAM Frequency [Auto]
Command Rate [Auto]
> Intel PPM/Turbo Mode Configuraiton
>
>
> Voltage Control
DRAM Timing Configuration
Clock Gen Configuration
Memory Test [Enabled]
Exit
Op ti ons
Disabled
Enabled
Step 2
Save and Exit from CMOS setup and reboot the system to activate this test.
Run this test for 5 minutes (minimum) to ensure the memory stability.
Step 3
When the process is done, change the setting back from “Enable” to “Disable”
to complete the test.
