Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
SOCKET 1366
Intel Core i7 Extreme / Core i7 processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyp er Threading
QPI Support 6.4GT/s
Chipset
Intel X58
Intel ICH1 0R
Super I/O
IT8720
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
Hardware Monitor Controller
Fan Sp eed Contro ller
ITE's "S mart Guard ian" funct ion
Main
Memory
DIMM Slots x 6
Each DIMM supports 512MB / 1GB / 2GB /
4GB DDR3
Max Memory Capicity 24GB
Dual & Tr ip le Channe l Mode DDR3 memory modu le
Supports DDR3 1866(OC) / 1600(OC) / 1333 / 1066 /
800
Registered DIMM and ECC DIMM is not supported
IDE JMB363
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA II ICH10R
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specificat ion co mp liant.
RAID 0 / 1 / 5 / 10 support
eSATA JMB363
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specificat ion co mp liant.
Port-Multiplier/RAID 0,1 support
LAN
Realtek RTL 8111C x2 (TPower X58)
Realtek RTL 8111C x1 (TPower X58A)
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC888S
7.1 channels audio out
High Definition Audio
IEEE 1394 Ti tsb43ab22a (TPower X58)
PCI slot x2 Supports PCI expansion cards
PCI Express Gen2 x16 slot (x16) x2 Supports PCI-E Gen2 x16 expansion cards
PCI Express Gen2 x16 slot (x4) x1 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI Express x1 slot x1 Supports PCI-E x1 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
On Board
Connector
Front Panel Connector x1 Supports front panel facilities
