Biostar J4105TH Версия 6.x [38/55] 内存容量

8 | 第二章: 硬件安装

步骤1: 将DIMM按顺序放在插槽上， DIMM上的切口须与插槽凹口匹配。

步骤2: 插入DIMM并固定好，直到固定夹跳回原位，DIMM就位。

如果DIMM未顺利插入，请勿强行按压。将DIMM拔出，再重插一次。

内存容量

DIMM插槽位置 DDR4 SO-DIMM模组

SODIMMB1 最大内存容量为8GB
