4 | Chapter 1: Introducon
1.2 Specifications
Specicaons
CPU Support Intel® Celeron® J4105 processor
Memory
Supports Single Channel DDR4-1866/ 2133/ 2400
1x DDR4 SO-DIMM Memory Slot, Max. Supports up to 8 GB Memory
Each DIMM supports non-ECC 4GB DDR4 module
*
Please refer to www.biostar.com.tw for Memory support list.
Storage
1x SATA III Connector (6Gb/s)
1x Key E - M.2 (PCI-E2.0 + USB2.0): Supports Wi-Fi / Bluetooth Card / Intel CNVi Jeerson Peak
1x Key M - M.2_10Gb/s (PCI-E2.0): Supports PCI-E SSD
LAN
RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
2 Channels, High Denion Audio
USB
4x USB 3.1(Gen1) port (4 on rear I/Os)
3x USB 2.0 port (2 on rear I/Os and 1 via internal headers)
Rear I/Os
1x DC-IN (12V-IN)
1x HDMI Port
4x USB 3.1(Gen1) Port
2x USB 2.0 Port
1x LAN port
2x Audio Jack
Internal I/Os
1x SATA III - 6Gb/s Connector
1x USB 2.0 Header: 1*5 Pin (each header supports 1 USB 2.0 ports)
1x SATA Power Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Inverter Header
1x LCD Voltage select Jumper Header
1x LCD Backlight Inverter Power Select Jumper Header
1x Clear CMOS Header
1x Internal Stereo Speaker Header
1x LVDS Header
2x 5050 LED Header
Form Factor Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 10(64bit)
*
Biostar reserves the right to add or remove support for any OS with or without noce.
