Руководство пользователя Страница: 8

Biostar J4105TH Версия 6.x [8/55] Memory capacity

8 | Chapter 2: Hardware installaon

Step 1: Align a DIMM on the slot such that the notch on the DIMM matches the break on the

Slot.

Step 2: Insert the DIMM rmly into the slot unl the retaining chip snap back in place and the

DIMM is properly seated.

Note

 IftheDIMMdoesnotgoinsmoothly,donotforceit.Pullitallthewayoutandtryagain.

Memory Capacity

DIMM Socket Locaon DDR4 SO-DIMM Module

SODIMMB1 Max up to 8 GB Memory
