Planet VC-234 [15/32] Led color function

n VDSL

LED Color Function

VDSL Green

Lit

Indicate that the VDSL link is

established.

Fast

Blink

Indicate that the VDSL link is at training

status (about 10 seconds).

Slow

Blink

Indicate that the VDSL link is at idle

status.

CO Green Lit

Indicate the VDSL Bridge is running at

CO mode.

CPE Green Lit

Indicate the VDSL Bridge is running at

CPE mode.

n 10/100Base-TX Port

LED Color Function

LNK/

ACT

Green

Lit

Indicate that the port is link up at

10/100Mbps.

Blink

Indicate that the VDSL Bridge is actively

sending or receiving data over that

port.

Off Indicate that the port is link down.
