Planet VC-234 [7/32] Lan to lan connection
![Planet VC-234 [7/32] Lan to lan connection](/views2/1071106/page7/bg7.png)
7
LAN to LAN Connection
Telephone wire
100Base-TX UTP
VDSL2
VDSL2
Ethernet Telephone Network
Main office/PBX,
Telco CO,
wire closet
VDSL2
Telephone wire
Up to 1.4km
VDSL2
Telephone wire
Ethernet over VDSL2 and Telephone Network
Main office/PBX,
Telco CO,
wire closet
LAN1
LAN2
VC-234/CO VC-234/CPE
Up to 1.4km
VDSL2
Telephone wire
Ethernet over VDSL2 and Telephone Network
Main office/PBX,
Telco CO,
wire closet
LAN1
LAN2
VC-231/CO VC-231/CPE
Splitter Splitter
