6
rate at 1.4km. This capability is ideal for use as an Ethernet
extender for your existing Ethernet network.
PLANET’s VDSL2 Converter solution provides a much cheaper
replacement and smooth migration for existing Long Reach
Ethernet (LRE) networks.
The cable specications of the connection are listed as following:
10Base-T, Category 3, 4 or 5 UTP
100Base-TX, Category 5 UTP
Ethernet over VDSL, Twisted-pair telephone wires
The two drawings listed below are typical application for the
Ethernet over VDSL2 Converter.
Note
Slave device (CPE) must connect to Master device
(CO) through the telephone wire. Slave cannot
connect to Slave and Master cannot connect to
Master. To define the VC-231 / VC-234 to CO or
CPE, please refer to section 2.2.1 for more detail.
l
l
l
