Planet VC-234 [26/32] Power information
![Planet VC-234 [26/32] Power information](/views2/1071106/page26/bg1a.png)
26
4. Power Information
The power jack of VC-231 / VC-234 is with 2.5mm in the central
post and required +5VDC power input. It will conform to the
bundled AC-DC adapter and Planet’s Media Chassis. Should you
have the issue to make the power connection, please contact
your local sales representative.
Please keep the AC-DC adapter as spare parts when your VC-
231 is installed to a Media Chassis.
2.5mm
DC Receptacle 2.5mm
+5V for each slot
DC receptacle is 2.5mm wide that conforms to and
matches the VDSL2 Converter 2.5mm DC jack’s central
post. Do not install any improper unit, model of the
Ethernet Over VDSL2 Converter.
