TA880GU3+ BIOS Manual
24
Slot Power Limit, W (Only for Port #02)
Options: 75 (Default) / 0-255
NB-SB Port Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
NP NB-SB VC1 Traffic Support [Disabled]
Link Width [Auto]
NB-SB Link ASPM [L1]
Options
Disabled
L1
NB-SB Link ASPM
Options: L1 (Default) / Disabled
NP NB-SB VC1 Traffic Support
Options: Disabled (Default) / Enabled
Link Width
Options: Auto (Default) / x1 / x2 / x4
Primary Video Controller
This option allows you to select the video controller in charge.
Options: PCI-GFX0-GPP-IGFX (Default) / GFX0-GPP-IGFX-PCI /
GPP-GFX0-IGFX-PCI / IGFX-GFX0-GPP-PCI
NB Power Management Features
This option controls the NB power management function.
Options: Auto (Default) / Disabled
