TA880GU3+ BIOS Manual
25
South Bridge Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
> SB Azalia Audio Configuration
SouthBridge Chipset Configuration
> SB USB Configuration
> SB SATA Configuration
SB CIMx Version : X.X.X.X
Options for SB HD
Azalia
SB Azalia Audio Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Onchip HD Azalia Configuration
HD Audio Azalia Device [Enabled]
Options
Auto
Dis
Enabled
abled
HD Audio Azalia Device
This item allows you to control the HD audio device.
Options: Enabled (Default) / Auto / Disabled
