TA880GU3+ BIOS Manual
35
DRAM Timing Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
DRAM Timing Configuration
> BIOSTAR Memory Insight
Memory Clock Mode [Auto]
Memclock Value [DDR3-800]
DRAM Timing Mode [Auto]
Memory CLK :
CAS Latency(Tcl) :
RAS/CAS Delay(Trcd) :
Row Precharge Time(Trp):
Min Active RAS(Tras) :
RAS/RAS Delay(Trrd) :
Row Cycle (Trc) :
Write Recover Time(Twr):
BIOSTAR Memory Insight
T-Series
BIOSTAR Memory Insight
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
BIOSTAR Memory Insight
DDR3-A1 SPD Informations
DDR3-B1 SPD Informations
DDR3-A2 SPD Informations
DDR3-B2 SPD Informations
DDR3-A1 SPD Informatio
T-Series
DDR3-A1/B1/A2/B2 SPD Informations
These items display SPD information of DDR3 memory.
