TA880GU3+ BIOS Manual
34
Voltage Configuration
BIOS SETUP UTILITY
T-Series
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Voltage Configuration
DDR Voltage :
HT Voltage :
NB Voltage :
NB IO :
SB Voltage :
Memory Over Voltage
NB Over Voltage
HT Over Voltage
[1.60V]
[Auto]
[Auto]
Change memory voltage
value.
Memory Over Voltage
This item allows you to change Memory voltage value.
NB Over Voltage
This item allows you to change NB voltage value.
HT Over Voltage
This item allows you to change HT voltage value.
