TA880GU3+ BIOS Manual
27
OnChip SATA Type
This option allows you to select the on-chip Serial ATA operation mode.
Options: Native IDE (Default) / RAID / AHCI / Legacy IDE / IDEÆAHCI
SATA IDE Combined Mode
This option controls the SATA/PATA combined mode.
Options: Enabled (Default) / Disabled
SATA III Mode
This option allows you to limit SATA Capability.
Options: Enabled (Default) / Disabled
Onboard Peripherals Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enable/Disable
Onboard Realtek
PCIE Network
Controller
MAC ID Information :
Realtek PCIE NIC [Enabled]
Realtek Option ROM [Disabled]
USB 3.0 Controller [Enabled]
Chipset
MAC ID Information
This area shows the MAC ID.
Realtek PCIE NIC
This option allows you to control the onboard LAN controller.
Options: Enable (Default) / Disable
Realtek Option ROM
This item allows you to enable or disable the Onboard LAN Boot ROM.
Options: Disabled (Default) / Enabled
USB 3.0 Controller
This item allows you to enable or disable USB 3.0 Controller.
Options: Disabled (Default) / Enabled
