TA880GU3+ BIOS Manual
43
CMOS Backup Function
It allows users to save different CMOS settings into BIOS-ROM and reload any
saved CMOS setting for customizing system configurations.
Moreover, users are able to save an ideal overclock setting during overclock
operation.
There are 10 sets of record address es in total, and users are able to nam e the CMOS
data according to personal preference.
BIOS SETU P UTILITY
Main Advan ced PCIPnP Boot Chipset T-Series
vxx .xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Exit Options
Security Setti ngs
Save Changes a nd Exit
Discard Change s and Exit
Discard Change s
Load Optimal D efaults
> Security
CMOS Backup Fu nction
Exit
CMOS Backup Func
CMOS Data
CMOS Data Reload
Save
Security
This sub-menu allows you to provide/revise supervisor and user password.
BIOS SETU P UTILITY
vxx .xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Install or Change the
password.
Security Setti ngs
Supervisor Pas sword :Not Installe d
User Password :Not Installe d
Change Supervi sor Password
User Access Le vel [Ful l Access]
Change User Pa ssword
Clear User Pas sword
Password Check [Set up]
Boot Sector Vi rus Protection [Dis abled]
Exit
