TA880GU3+ BIOS Manual
28
6 T-Series Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
=========== Automate OverClock System ===========
============ Manual OverClock System ============
Notice: Please Clear CMOS if system no display
after overclocking.
OverClock Navigator [Normal]
> G.P.U Phase Control
Integrated Memory Test [Disabled]
BIO-unlocKING [Disabled]
Auto OverClock System [V6-Tech Engine]
CPU/HT Reference Clock (MHz) [200]
CPU Configuration [Auto]
> CPU Tuning
> Clock Control
> Voltage Configuration
> DRAM Timing Configuration
> Memory Configuration
Exit
BIO-unlocKING
This item allows you to activate BIO-unlocKING function.
Options: Disabled(Default) / Enabled
OverClock Navigator
OverClock .Navigator is designed for beginners in overclock field.
Based on many test and experiments from Biostar Engineer Team, OverClock
Navigator provides 3 default overclock configurations that are able to raise the
system performance.
Options: Normal (Default) / Automate OverClock / Manual OverClock
