TA880GU3+ BIOS Manual
26
SB USB Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
OHCI HC(Bus 0 Dev 18 Fn 0) [Enabled]
Onchip USB Configuration
OHCI HC(Bus 0 Dev 19 Fn 0) [Enabled]
OHCI HC(Bus 0 Dev 22 Fn 0) [Enabled]
OHCI HC(Bus 0 Dev 20 Fn 5) [Enabled]
Options
Disabled
Enabled
OHCI HC (Bus 0 Dev 18/19/20/22 Fn 0/5)
This item allows you to control OHCI host controller. (USB 1.1 Device)
Options: Enabled (Default) / Disabled
SB SATA Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
OnChip SATA Channel [Enabled]
Onchip SATA Configuration
OnChip SATA Type [Native IDE]
SATA IDE Combined Mode [Enabled]
SATA-III Mode [Auto]
Options
Disabled
Enabled
OnChip SATA Channel
This option allows you to enable the on-chip Serial ATA.
Options: Enabled (Default) / Disabled
