TA770E3/TA770XE3/TA790XE3
25
Manual Overclock System (M.O.S.)
MOS is designed for experienced overclock users.
It allows users to customize personal overclock settings.
BIOS SETUP UTILITY
Main Advanced
PCIP nP Boot
Chip set T-Series
vxx. xx (C)Copyright 1 985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Sav e and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
=========== Automate OverClock System ===========
============ Manual OverClock System ============
WARNING: Please Clear CMOS if system no display
afte r overclocking.
OverClock Navigator [Normal]
Aut o OverClock System [V6 -Tech Engine]
> Over-Voltage Configuration
CPU Frequency [200]
> CPU FID/VID Control
> D RAM Timing Confi guation
> Hyper Transport Configuration
> M emory Configurat ion
> G.P.U Phase Control
Integrated Memory Test [Disabled]
Exit
Opti ons
Normal
Automate OverClock
Man ual OverClock
Options
Norm al
Auto mate OverClock
Manual OverClock
↓
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx. xx (C)Copyright 1 985-200x, American Me gatrends, In c.
Select Screen
Select Item
Change Option
General Help
Sav e and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
=========== Automate OverClock System ===========
============ Manual OverClock System ============
WARNING: Please Clear CMOS if system no display
afte r overclocking.
OverClock Navigator [Manual OverClock]
Aut o OverClock System [V6 -Tech Engine ]
> Over-Voltage Configuration
CPU Frequency [200]
> CPU FID/VID Control
> D RAM Timing Confi guation
> Hyper Transport Configuration
> M emory Configurat ion
> G.P.U Phase Control
Integrated Memory Test [Disabled]
Exit
Opti ons
Normal
Automate OverClock
Man ual OverClock
Over-Voltage Configuration
Enter this function for more advanced voltage settings.
CPU Frequency
CPU Frequency is directly in proportion to system performance. To
maintain the system stability, CPU voltage needs to be increased also
when raising CPU frequency.
CPU FID/VID Control
Enter this function for more advanced CPU settings.
DRAM Timing Configuration
Enter this function for more advanced DRAM clock settings.
