Motherboard Manual
54
PORTUGUESE
TA770E3/TA770XE3 TA790XE3
CPU
Socket AM3
Processadores AthlonII / Phenom II
A arquitectura AMD 64 p ermite uma comput ação
de 32 e 64 bits
Suporta as tecnologias Hyper Transport 3.0
(Watt máximo: 125W)
Socket AM3
Processadores AthlonII / Phenom II
A arquitectura AMD 64 p ermite uma comput ação
de 32 e 64 bits
Suporta as tecnologias Hyper Transport 3.0
(Watt máximo: 125W)
FSB
Suporta a tecnologia HyperTransport 3.0 com
uma largura de banda até 5.2 GT/s
Suporta a tecnologia HyperTransport 3.0 com
uma largura de banda até 5.2 GT/s
Chipset
AMD 770
AMD SB710
AMD 790X
AMD SB750
Especificaçã
o Super I/O
ITE IT8718F
Proporciona as funcionalidades mais utilizadas
em termos da especificação Super I/O.
Interface LPC (Low Pin Count).
In ic iat ivas para contro lo do amb iente
Monitorização do hardware
Controlador da velocidade da ventoinha
Função "Smart Guard ian" da ITE
ITE IT8718F
Proporciona as funcionalidades mais utilizadas
em termos da especificação Super I/O.
Interface LPC (Low Pin Count).
In ic iat ivas para contro lo do amb iente
Monitorização do hardware
Controlador da velocidade da ventoinha
Função "Smart Guard ian" da ITE
Memória
principal
Ranhuras DIMM DDR3 x 4
Cada módulo DIMM suporta uma memória
DDR3 de 256MB/512MB/ 1GB/2GB/4GB
Capacidad e máx ima de memória: 16GB
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 800 / 1066 / 1333
Suporta módulos DDR3 1600 (OC)
Os módulos DIMM registados e os DIMM ECC
não são suportados
Ranhuras DIMM DDR3 x 4
Cada módulo DIMM suporta uma memória
DDR3 de 256MB/512MB/ 1GB/2GB/4GB
Capacidad e máx ima de memória: 16GB
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 800 / 1066 / 1333
Suporta módulos DDR3 1600 (OC)
Os módulos DIMM registados e os DIMM ECC
não são suportados
IDE
AMD SB710
Modo Bus master Ultra DMA 33 / 66 / 100 / 133
Suporta o modo PIO 0~4,
AMD SB750
Modo Bus master Ultra DMA 33 / 66 / 100 / 133
Suporta o modo PIO 0~4,
SATA II
AMD SB710
Velocidades de transmissão de dados até 3 Gb/s.
Compat ibilidade co m a especificação SATA
versão 2.0.
Suporta as funções RAID 0,1,1+0
AMD SB750
Velocidades de transmissão de dados até 3 Gb/s.
Compat ibilidade co m a especificação SATA
versão 2.0.
Suporta as funções RAID 0,1,5,1+0
LAN
Realtek RTL 8111DL
Auto negociação de 10 / 100 / 1000 Mb/s
Capacidade semi/full-duplex
Realtek RTL 8111DL
Auto negociação de 10 / 100 / 1000 Mb/s
Capacidade semi/full-duplex
Codec de
som
ALC662
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
ALC662
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
