Motherboard Manual
56
POLISH
TA770E3/TA770XE3 TA790XE3
Procesor
Socket AM3
AthlonII / Phenom II Procesory
Architektura AMD 64 umożliwia przetwarzanie
32 i 64 bitowe
Obsługa Hyper Transport 3.0
(Maksymalny Watt: 125W)
Socket AM3
AthlonII / Phenom II Procesory
Architektura AMD 64 umożliwia przetwarzanie
32 i 64 bitowe
Obsługa Hyper Transport 3.0
(Maksymalny Watt: 125W)
FSB
Obsługa HyperTransport 3.0 o szerokości pasma
do 5.2 GT/s
Obsługa HyperTransport 3.0 o szerokości pasma
do 5.2 GT/s
Chipset
AMD 770
AMD SB710
AMD 790X
AMD SB750
Pamięć
główna
Gniazda DDR3 DIMM x 4
Każde gniazdo DIMM obsługuje moduły
256MB/512MB/1GB/2GB/4GB DDR3
Maks. wielkość pamięci 16GB
Modu ł pamięci DDR3 z trybem podwójnego
kanału
Obsługa DDR3 800 / 1066 / 1333
Obsługa DDR3 1600 (OC)
Brak obsługi Registered DIMM oraz ECC DIMM
Gniazda DDR3 DIMM x 4
Każde gniazdo DIMM obsługuje moduły
256MB/512MB/1GB/2GB/4GB DDR3
Maks. wielkość pamięci 16GB
Modu ł pamięci DDR3 z trybem podwójnego
kanału
Obsługa DDR3 800 / 1066 / 1333
Obsługa DDR3 1600 (OC)
Brak obsługi Registered DIMM oraz ECC DIMM
Super I/O
ITE IT8718F
Zapewnia najbardziej powszechne funkcje Super
I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H/W
Kontroler prędkości wentylatora
Funkcja ITE "Smart Guard ian"
ITE IT8718F
Zapewnia najbardziej powszechne funkcje Super
I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H/W
Kontroler prędkości wentylatora
Funkcja ITE "Smart Guard ian"
IDE
AMD SB710
Ultra DMA 33 / 66 / 100 / 133 Tryb Bus Master
obsługa PIO tryb 0~4,
AMD SB750
Ultra DMA 33 / 66 / 100 / 133 Tryb Bus Master
obsługa PIO tryb 0~4,
SATA II
AMD SB710
Transfer danych do 3 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0.
Obsługa RAID 0,1,1+0
AMD SB750
Transfer danych do 3 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0.
Obsługa RAID 0,1,5,1+0
LAN
Realtek RTL 8111DL
10 / 100 / 1000 Mb/s z automatyczną negocjacją
szybkości
Działanie w trybie połowicznego/pełnego
dupleksu
Realtek RTL 8111DL
10 / 100 / 1000 Mb/s z automatyczną negocjacją
szybkości
Działanie w trybie połowicznego/pełnego
dupleksu
Kodek
dźwiękowy
ALC662
5.1 kanałowe wyjście audio
Obsługa High- Def in ition Aud io
ALC662
5.1 kanałowe wyjście audio
Obsługa High- Def in ition Aud io
