TA770E3/TA770XE3/TA790XE3
51
TA770E3/TA770XE3 TA790XE3
Alloggio PC I x3 Alloggio PC I x3
Alloggio PCI Express Gen2 x16 x1 Alloggio PCI Express Gen2 x16 x1
Alloggi
Alloggio PCI Express Gen2 x1 x2 Alloggio PCI Express Gen2 x1 x2
Connettore floppy x1 Connettore floppy x1
Connettore IDE x1 Connettore IDE x1
Connettore SATA x6 Connettore SATA x6
Connettore pannello frontale x1 Connettore pannello frontale x1
Connettore audio frontale x1 Connettore audio frontale x1
Connettore CD-in x1 Connettore CD-in x1
Connettore output S/PDIF x1 Connettore output S/PDIF x1
Collettore ventolina C PU x1 Collettore ventolina C PU x1
Collettore ventolina sistema x2 Collettore ventolina sistema x2
Collettore cancellaz ione CMOS x1 Collettore cancellaz ione CMOS x1
Connettore USB x3 Connettore USB x3
Connettore Porta seriale x1 Connettore Porta seriale x1
Connettore alimentazione(24 pin) x1 Connettore alimentazione(24 pin) x1
Connettori
su scheda
Connettore alimentazione(4 pin) x1 Connettore alimentazione(4 pin) x1
I/O
pannello
posteriore
Tas t iera PS/2 x 1
Mous e PS/2 x1
Porta LAN x1
Porta USB x6
Connettore audio x3
Tas t iera PS/2 x 1
Mous e PS/2 x1
Porta LAN x1
Porta USB x6
Connettore audio x3
Dimension
i scheda
220mm (larghezza) x 305 mm (altezza) 220mm (larghezza) x 305 mm (altezza)
Sistemi
operativi
supportati
Windows XP / Vista / 7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
Windows XP / Vista / 7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
